USB interface for communication between PC and X650.

Three highly reliable axis gyroscopes and accelerometer.

Embedded AVR and 51 chips, MCU structure, balance control guarantee.

#Xaircraft superx flight control system software#

X650 new software interface for flight control management. Support UltraPWM protocols and the control frequency up to 500Hz (2ms).Continue to provide 35A output current in the 3s battery.Up to 60 MOS, able to withstand the high current.4 Electric speed control device designed into one, line connect easy and safe.X650 ESC-A4 High-Speed (UltraPWM) Electric Speed Control Device

1 Link interface for connecting USB-Link or wireless module.

5 expansion module interface for connecting AHRS, GPS, RF modules.

2 built-in modules: input control signal module and output module.

12-channel control signal output, ALL channel support UltraPWM ESC, General Electric Adjustment, high-speed digital servo, general servo.

Output: Euler angles (Pitch, Roll, Yaw) (units deg), 3-axis angular velocity (in deg/s), 3-axis acceleration (in g).

Flight controller: Provide 12-channel control signals input, X650 quadcopter/quadrotor need 4 channels for basic flying at least, if you want to adjust the shutter and the camera angle, you need two additional channels, the remaining channels for extension using, such as GPS fixed-point, fixed height, fixed direction. Propellers driven by brushless motors deirectly offer efficiency of up to 9g/W under rated load, each group of propeller and motor can provide thrust as much as 700g, which ensures the sate flight with 1600g take-off weight at most. It will not easy to crack at low temperature. Propeller & BrushLess Motor Exclusive efficient propellers, good quality in folding endurance and breaking-proof. Optional for uniaxial steering engine or biaxial. The damping design filter the high-frequency vibration, and the flight control algorithms control the steering gear to filter the low frequency jitters and make the equipment balance automatically.

#Xaircraft superx flight control system plus#

Damping design plus flight control algorithms ensures the high quality of the photos and videos taken in flight period.

With the help of XAircraft flight control algorithms, the X650 is easier to fly than other types of helicopters, and has quite good stability.įrame X650 quadcopter/quadrotor mainly use aluminum alloy and glass fiber materials make sure the mechanical structure is durable and shatter-resistant.Īnti-Vibration Camera Mount Made of glass fiber. Support 13 sensors as flight attitude, height, direction, position (XAircraft GPS Module-Require additional purchase), temperature, and power consumption. Compared with traditional helicopters, the X650 quadcopter/quadrotor is a ideal platform for first person flight(FPV) to bringing you a brand-new flying experience. Fly forward, backward, left, right, up, down… by radio control equipment. It flies stably by four well controlled individual propellers(12-inch 60-pitch) direct-driven from four brushless motors.

XAircraft X650 is a remote control four rotor mini helicopter designed for the model aircraft enthusiasts which powered by lithium battery.
